MAX312CPE+

MAX312CPE+

  • Part No .:

    MAX312CPE+
  • Manufacturer:

    Maxim Integrated
  • Description:

    IC
  • Remark:

    new origin
  • Last Updated:

    2020/09/27
  • Product Details

Data sheet


Physical
Case/Package DIP
Mount Through Hole
Number of Pins 16
Technical
Drain to Source Resistance 10 Ω
Dual Supply Voltage 9 V
Max Dual Supply Voltage 20 V
Max Operating Temperature 70 °C
Max Power Dissipation 842 mW
Max Supply Current 1 µA
Max Supply Voltage 30 V
Min Dual Supply Voltage 4.5 V
Min Operating Temperature 0 °C
Min Supply Voltage 4.5 V
Nominal Supply Current 5 µA
Number of Channels 4
On-State Resistance 10 Ω
Operating Supply Voltage 18 V
Supply Type Single , Dual
Termination Through Hole
Throw Configuration SPST
Turn-Off Delay Time 235 ns
Turn-On Delay Time 275 ns
Dimensions
Height 4.45 mm
Length 19.43 mm
Width 7.87 mm
Compliance
Lead Free Lead Free
REACH SVHC Unknown
Radiation Hardening No
RoHS Compliant

SWITCH, QUAD SPST, DIP16, 312; Switch Type, Analogue:SPST; Switches, No. of:4; Voltage, Supply Source:Dual; Resistance, On State:6.5ohm; Voltage, Supply Min:4.5V; Voltage, Supply Max:20V; Termination Type:Through Hole; Case Style:DIP; No. of Pins:16; Operating Temperature Range:0°C to +70°C; Base Number:312; IC Generic Number:312; Logic Function Number:312; No. of Channels:4; Resistance, Rds On:10ohm; Temp, Op. Max:70°C; Temp, Op. Min:0°C; Temperature Range, IC:Commercial
