Part No .:
UC2907DWTRG4Manufacturer:
Texas InstrumentsDescription:
ICRemark:
new originLast Updated:
2025/10/25
|
Physical
|
|
| Case/Package | SOIC |
| Number of Pins | 16 |
| Weight | 0.016709 oz |
|
Technical
|
|
| Input Current | 6 mA |
| Max Operating Temperature | 85 °C |
| Min Operating Temperature | -40 °C |
| Operating Supply Current | 6 mA |
| Operating Supply Voltage | 35 V |
|
Dimensions
|
|
| Height | 2.35 mm |
| Length | 10.28 mm |
|
Compliance
|
|
| Lead Free | Lead Free |
| Radiation Hardening | No |
| RoHS | Compliant |
