MAX339EEE+T

MAX339EEE+T

  • Part No .:

    MAX339EEE+T
  • Manufacturer:

    Maxim Integrated
  • Description:

    IC
  • Remark:

    new origin
  • Last Updated:

    2020/10/30
  • Product Details
Physical
Case/Package SSOP
Mount Surface Mount
Number of Pins 16
Technical
Logic Function Multiplexer
Max Dual Supply Voltage 20 V
Max Operating Temperature 85 °C
Max Supply Voltage 30 V
Min Dual Supply Voltage 4.5 V
Min Operating Temperature -40 °C
Min Supply Voltage 4.5 V
On-State Resistance 400 Ω
Operating Supply Current 1 µA
Supply Type Single , Dual
Compliance
Radiation Hardening No
RoHS Non-Compliant



Maxim Integrated
MAX339EEE+T
Analog Multiplexer Dual 4:1 16-Pin QSOP T/R



SEND A MESSAGE
You can contact us any way that is convenient for you. We are available 24/7 via fax, email or telephone.
MAX339EEE+T
If you have questions or suggestions,please leave us a message,we will reply you as soon as we can!

Related Product

MAX7219CWG

MAX7219CWG

Data sheet  Physical   Case/Package SOIC Contact Plating Tin Mount Surface Mount Number of Pins 24 Weight 0.025909 oz Technical   High Level Output Current -2 mA Interface Serial Low Level Output Current 5 mA Max Input Voltage 5.5 V Max Operating Temperature 70 °C LED DRIVER 8 DIGIT CC, SMD, 7219; LED Driver Application:Displays, Panel Meters; Topology:Common Cathode; No. of Outputs:8; Output Current:320mA; Output Voltage:4.5V; Input Voltage:4V to 5.5V; Dimming Control Type:Analogue / Digital; Operating Temperature Range:0°C to +70°C; Driver Case Style:SOIC; Switching Frequency:10MHz; Base Number:7219; Character Type:8 Digit; Data / Control Interface:Serial 4 Wire; Device Type:LED; IC Generic Number:7219; IC Temperature Range:Commercial; Interface Type:Common Cathode; LED Display Type:7 Segment / Bar Graph; Logic Function Number:7219; No. of Pins:24; No. of Segments:7; Operating Temperature Max:70°C; Operating Temperature Min:0°C; Package / Case:SOIC; Supply Voltage Max:5.5V; Supply Voltage Min:4V; Termination Type:SMD

MAX307CPI+

MAX307CPI+

Data sheet Physical   Case/Package PDIP Mount Through Hole Number of Pins 28 Technical   Dual Supply Voltage 9 V Logic Function Multiplexer Max Dual Supply Voltage 20 V Max Operating Temperature 70 °C Max Power Dissipation 727 mW Max Supply Voltage 30 V Min Dual Supply Voltage 4.5 V Min Operating Temperature 0 °C Min Supply Voltage 5 V Number of Channels 2 Number of Circuits 2 On-State Resistance 175 Ω Operating Supply Current 500 µA Operating Supply Voltage 28 V Propagation Delay 300 ns Supply Type Single , Dual Turn-Off Delay Time 300 ns Turn-On Delay Time 600 ns Dimensions   Height 4.45 mm Length 37.34 mm Width 14.61 mm Compliance   Lead Free Lead Free REACH SVHC Unknown Radiation Hardening No RoHS Compliant The MAX306/MAX307 precision, monolithic, CMOS analog multiplexers (muxes) offer low on-resistance (less than 100Ω), which is matched to within 5Ω between channels and remains flat over the specified analog signal range (7Ω, max). They also offer low leakage over temperature (INO(OFF) less than 2.5nA at +85°C) and fast switching speeds (tTRANS less than 250ns). The MAX306 is a single-ended 1-of-16 device, and the MAX307 is a differential 2-of-8 device. The MAX306/MAX307 are fabricated with Maxim’s improved 44V silicon-gate process. Design improvements yield extremely low charge injection (less than 10pC) and guarantee electrostatic discharge (ESD) protection greater than 2000V. These muxes operate with a single +5V to +30V supply, or bipolar ±4.5V to ±20V supplies, while retaining TTL/ CMOS-logic input compatibility and fast switching. CMOS inputs provide reduced input loading. These improved parts are plug-in upgrades for the industrystandard DG406, DG407, DG506A, and DG507A.

MAX314LCUE+T

MAX314LCUE+T

Data sheet  Physical   Case/Package TSSOP Mount Surface Mount Number of Pins 16 Technical   Max Dual Supply Voltage 20 V Max Operating Temperature 70 °C Max Power Dissipation 842 mW Max Supply Current 200 µA Max Supply Voltage 36 V Min Dual Supply Voltage 4.5 V Min Operating Temperature 0 °C Min Supply Voltage 4.5 V Nominal Supply Current 5 µA On-State Resistance 10 Ω Operating Supply Voltage 18 V Supply Type Single , Dual Throw Configuration SPST Turn-Off Delay Time 235 ns Turn-On Delay Time 275 ns Compliance   Lead Free Lead Free Radiation Hardening No RoHS Compliant Maxim’s MAX312/MAX313/MAX314 analog switches feature low on-resistance (10Ω max) and 1.5Ω on-resistance matching between channels. These switches conduct equally well in either direction. They offer low leakage over temperature (2.5nA at +85°C). Low power consumption and ESD tolerance greater than 2000V per Method 3015.7 are guaranteed. The MAX312/MAX313/MAX314 are quad, singlepole/single-throw (SPST) analog switches. The MAX312 is normally closed (NC), and the MAX313 is normally open (NO). The MAX314 has two NC switches and two NO switches. All three devices operate from a single supply of +4.5V to +30V or from dual supplies of ±4.5V to ±20V.  Applications: Test Equipment  Communication Systems  PBX, PABX Systems  Audio Signal Routing Avionics  Sample-and-Hold Circuits  Data Acquisition Systems

MAX354CWE

MAX354CWE

Data sheet Physical   Case/Package SOIC Contact Plating Tin Mount Surface Mount Number of Pins 16 Technical   High Level Output Current 30 mA Logic Function Multiplexer Max Dual Supply Voltage 18 V Max Operating Temperature 70 °C Max Power Dissipation 762 mW Max Supply Voltage 36 V Min Dual Supply Voltage 4.5 V Min Operating Temperature 0 °C Min Supply Voltage 4.5 V Number of Channels 1 Number of Circuits 1 On-State Resistance 350 Ω Operating Supply Current 300 µA Operating Supply Voltage 28 V Propagation Delay 250 ns Supply Type Single , Dual Throw Configuration DPST Turn-Off Delay Time 200 ns Turn-On Delay Time 250 ns Dimensions   Height 2.35 mm Length 10.5 mm Width 7.6 mm Compliance   Lead Free Lead Free REACH SVHC Unknown Radiation Hardening No RoHS Compliant The MAX354/MAX355 fault-protected multiplexers (muxes) use a series N-channel, P-channel, N-channel structure that protects the devices from overvoltage up to 40V beyond the supply rails during power-up, powerdown, and fault conditions. The MAX354/MAX355 also protect sensitive circuit components against voltages near or beyond the normal supplies. The MAX354 single 8-channel mux and the MAX355 dual 4-channel mux protect analog signals while operating from a single 4.5V to 36V supply or ±4.5V to ±18V dual supplies. These muxes have 350Ω on-resistance and can be used for demultiplexing as well as multiplexing. Input leakage current is less than 0.5nA at +25°C and less than 5nA at +85°C. All digital inputs have 0.8V and 2.4V logic thresholds, ensuring both TTL and CMOS logic compatibility without pull-up resistors. Break-before-make operation is guaranteed and power consumption is less than 1.5mW. Applications  Data-Acquisition Systems  Industrial and Process Control  Avionics ATE Equipment  Signal Routing  Redundant/Backup Systems

MAX312CPE+

MAX312CPE+

Data sheet  Physical   Case/Package DIP Mount Through Hole Number of Pins 16 Technical   Drain to Source Resistance 10 Ω Dual Supply Voltage 9 V Max Dual Supply Voltage 20 V Max Operating Temperature 70 °C Max Power Dissipation 842 mW Max Supply Current 1 µA Max Supply Voltage 30 V Min Dual Supply Voltage 4.5 V Min Operating Temperature 0 °C Min Supply Voltage 4.5 V Nominal Supply Current 5 µA Number of Channels 4 On-State Resistance 10 Ω Operating Supply Voltage 18 V Supply Type Single , Dual Termination Through Hole Throw Configuration SPST Turn-Off Delay Time 235 ns Turn-On Delay Time 275 ns Dimensions   Height 4.45 mm Length 19.43 mm Width 7.87 mm Compliance   Lead Free Lead Free REACH SVHC Unknown Radiation Hardening No RoHS Compliant SWITCH, QUAD SPST, DIP16, 312; Switch Type, Analogue:SPST; Switches, No. of:4; Voltage, Supply Source:Dual; Resistance, On State:6.5ohm; Voltage, Supply Min:4.5V; Voltage, Supply Max:20V; Termination Type:Through Hole; Case Style:DIP; No. of Pins:16; Operating Temperature Range:0°C to +70°C; Base Number:312; IC Generic Number:312; Logic Function Number:312; No. of Channels:4; Resistance, Rds On:10ohm; Temp, Op. Max:70°C; Temp, Op. Min:0°C; Temperature Range, IC:Commercial

MAX17102ETM+T

MAX17102ETM+T

Data sheet  Physical   Mount Surface Mount Number of Pins 48 Technical   Max Operating Temperature 85 °C Min Operating Temperature -40 °C Compliance   RoHS Compliant

MAX8660ETL/V+

MAX8660ETL/V+

Data sheet Physical   Number of Pins 40 Technical   Max Operating Temperature 85 °C Min Operating Temperature -40 °C Compliance   RoHS Compliant High-Efficiency, Low-Iq, PMICs with Dynamic Voltage Management for Mobile Applica

MAX1586CETM+

MAX1586CETM+

Data sheet Physical   Case/Package QFN Contact Plating Tin Mount Surface Mount Number of Pins 48 Technical   Frequency 1 MHz Max Input Voltage 5.5 V Max Operating Temperature 85 °C Max Output Current 1.2 A Max Output Voltage 5.5 V Max Power Dissipation 2.105 W Max Supply Voltage 5.5 V Min Input Voltage 2.6 V Min Operating Temperature -40 °C Min Output Voltage 700 mV Min Supply Voltage 2.4 V Number of Outputs 1 Output Current 1.3 A Output Voltage 1.25 V Power Dissipation 2.1 W Switching Frequency 1 MHz Termination SMD/SMT Compliance   Lead Free Lead Free Radiation Hardening No RoHS Compliant High-Efficiency, Low-IQ PMICs with Dynamic Core for PDAs and Smartphones

MAX17409GTI+

MAX17409GTI+

Data sheet  Physical   Mount Surface Mount Number of Pins 28 Technical   Max Duty Cycle 100% Max Operating Temperature 105 °C Min Operating Temperature -40 °C Number of Outputs 1 Operating Supply Current 1.5 mA Operating Supply Voltage 5.5 V Output Current 20 A Output Voltage 1.12 V Switching Frequency 600 kHz Compliance   RoHS Compliant Quick PWM NVIDIA CPU Controller 28-Pin TQFN EP

SN74LVC2G53YZAR

SN74LVC2G53YZAR

Data sheet Physical   Mount Surface Mount Number of Pins 8 Technical   Max Operating Temperature 85 °C Max Supply Current 1 µA Max Supply Voltage 5.5 V Min Operating Temperature -40 °C Min Supply Voltage 1.65 V Number of Channels 1 Number of Circuits 2 Number of Inputs 2 Number of Outputs 1 On-State Resistance 13 Ω Operating Supply Current 1 µA Operating Supply Voltage 5 V Polarity Non-Inverting Supply Type Single Throw Configuration SPDT Turn-Off Delay Time 9.4 ns Turn-On Delay Time 10.3 ns Compliance   Lead Free Lead Free RoHS Compliant IC SWITCH SPDT 8DSBGA

SNJ54HCT14J

SNJ54HCT14J

Data sheet  Physical   Case/Package CDIP Mount Through Hole Number of Pins 14 Technical   High Level Output Current -4 mA Logic Function Schmitt Trigger , Inverter Low Level Output Current 4 mA Max Operating Temperature 125 °C Max Supply Voltage 5.5 V Min Operating Temperature -55 °C Min Supply Voltage 4.5 V Number of Bits 6 Number of Elements 6 Number of Gates 6 Operating Supply Voltage 5 V Propagation Delay 48 ns Quiescent Current 2 µA Turn-On Delay Time 48 ns Compliance   Lead Free Contains Lead Radiation Hardening No RoHS Compliant Hex Schmitt-trigger Inverters 14-CDIP -55 to 125

AD420ARZ-32

AD420ARZ-32

Data sheet Physical   Case/Package SOIC Contact Plating Tin Number of Pins 24 Technical   Conversion Rate 400 S/s Differential Output No Integral Nonlinearity (INL) 0.012 LSB Interface SPI , Serial Max Input Voltage 4.995 V Max Operating Temperature 85 °C Max Output Voltage 9.5 V Max Power Dissipation 176 mW Max Supply Voltage 32 V Min Input Voltage 5.005 V Min Operating Temperature -40 °C Min Output Voltage 29.5 V Min Supply Voltage 12 V Nominal Supply Current 4.2 mA Number of Bits 16 Number of Channels 1 Number of Converters 1 Number of D/A Converters 1 Number of DAC Channels 1 Number of Outputs 1 Output Type Voltage Polarity Unipolar , Bipolar Reference Voltage 5 V Resolution 16 b Sampling Rate 400 S/s Settling Time 2.5 ms Termination SMD/SMT Dimensions   Height 2.65 mm Length 15.6 mm Width 7.6 mm Compliance   Lead Free Contains Lead REACH SVHC No SVHC Radiation Hardening No RoHS Compliant The AD420 is a complete digital to current loop output converter, designed to meet the needs of the industrial control market. It provides a high precision, fully integrated, low cost single-chip solution for generating current loop signals in a compact 24-pin SOIC or PDIP package. The output current range can be programmed to 4 mA-20 mA, 0 mA-20 mA or an overrange function of 0 mA-24 mA. The AD420 can alternatively provide a voltage output from a separate pin that can be configured to provide 0 V-5 V, 0 V-10 V, ±5 V or ±10 V with the addition of a single external buffer amplifier. The 3.3 M Baud serial input logic design minimizes the cost of galvanic isolation and allows for simple connection to commonly used microprocessors. It can be used in three-wire or asynchronous mode and a serial-out pin is provided to allow daisy chaining of multiple DACs on the current loop side of the isolation barrier. The AD420 uses sigma-delta (SD) DAC technology to achieve 16-bit monotonicity at very low cost. Full-scale settling to 0.1% occurs within 3 ms. The only external components that are required (in addition to normal transient protection circuitry) are three low cost capacitors which are used in the DAC output filter. If the AD420 is going to be used at extreme temperatures and supply voltages, an external output transistor can be used to minimize power dissipation on the chip via the "BOOST" pin. The FAULT DETECT pin signals when an open circuit occurs in the loop. The on-chip voltage reference can be used to supply a precision +5 V to external components in addition to the AD420 or, if the user desires temperature stability exceeding 25 ppm/°C, an external precision reference such as the AD586 can be used as the reference. The AD420 is available in a 24-pin SOIC and PDIP over the industrial temperature range of -40°C to +85°C.
