Part No .:
LIS344ALHTRManufacturer:
STMicroeletronicsDescription:
MEMSRemark:
new originLast Updated:
2026/05/16
MEMS inertial sensor high performance 3-axis ±2/±6g ultracompact linear accelerometer
|
Physical
|
|
| Case/Package | LGA |
| Contact Plating | Nickel , Gold |
| Mount | Surface Mount |
| Number of Pins | 1600% |
|
Technical
|
|
| Axis | X, Y, Z |
| Bandwidth | 2 kHz |
| Max Operating Temperature | 85 °C |
| Max Supply Voltage | 3.6 V |
| Min Operating Temperature | -40 °C |
| Min Supply Voltage | 2.4 V |
| Nominal Supply Current | 680 µA |
| Output Type | Analog |
| Sensitivity | 15000 mV/g |
|
Dimensions
|
|
| Height | 1.33 mm |
| Length | 4.15 mm |
| Width | 4.15 mm |
|
Compliance
|
|
| Lead Free | Lead Free |
| Radiation Hardening | No |
| RoHS | Compliant |
Data sheet Physical Mount Surface Mount Number of Pins 16 Technical Axis X, Y, Z Bandwidth 200 Hz Max Operating Temperature 85 °C Max Supply Voltage 3.6 V Min Operating Temperature -40 °C Min Supply Voltage 2.16 V Output Type SPI , I2C Compliance Lead Free Lead Free REACH SVHC No SVHC RoHS Compliant MEMS motion sensor: low-power high-g 3-axis digital accelerometer
MEMS motion sensor: low-power high-g 3-axis digital accelerometer The H3LIS100DL is a low-power highperformance 3-axis linear accelerometer belonging to the “nano” family, with digital I2C/SPI serial interface standard output. The device features ultra-low-power operational modes that allow advanced power saving and smart sleep-to-wakeup functions. The H3LIS100DL has a full scale of ±100 g and is capable of measuring accelerations with output data rates from 0.5 Hz to 400 Hz. The H3LIS100DL is available in a small thin plastic land grid array package (LGA) and is guaranteed to operate over an extended temperature range from -40 °C to +85 °C.
Data sheet Physical Case/Package QFN Mount Surface Mount Number of Pins 24 Technical Axis X, Y, Z Bandwidth 500 Hz Max Operating Temperature 105 °C Max Supply Voltage 3.6 V Min Operating Temperature -40 °C Min Supply Voltage 2.16 V Output Type SPI , I2C Compliance Lead Free Lead Free REACH SVHC No SVHC RoHS Compliant High-performance ultra-low-power 3-axis accelerometer with digital output for industrial applications
Data sheet Physical Case/Package QFN Contact Plating Tin Mount Surface Mount Number of Pins 2400% Technical Axis X, Y, Z Bandwidth 500 Hz Max Operating Temperature 105 °C Min Operating Temperature -40 °C Operating Supply Voltage 3.6 V Output Type SPI , I2C , Digital Compliance RoHS Compliant High-performance motion sensor for automotive applications: ultra-low-power digital output 3-axis accelerometer The AIS3624DQ is available in a small quad flat no-lead (QFN) package (4x4 mm footprint) and is guaranteed to operate over an extended temperature range from -40 °C to +105 °C. This product may be used in a variety of automotive non-safety applications such as: Motion-activated functions Telematic boxes Impact recognition and logging Vibration monitoring and compensation
Data sheet Physical Case/Package LGA Contact Plating Nickel , Gold Number of Pins 14 Technical Axis X, Y, Z Bandwidth 5.3 kHz Interface I2C , SPI Max Operating Temperature 85 °C Max Supply Voltage 3.6 V Max Supply Voltage (DC) 3.6 V Min Operating Temperature -40 °C Min Supply Voltage 1.71 V Min Supply Voltage (DC) 1.71 V Operating Supply Current 2 µA Output Type Digital Sensor Type 3 Axis Dimensions Height 1 mm Length 2.15 mm Width 2.15 mm Compliance Lead Free Lead Free REACH SVHC No SVHC Radiation Hardening No RoHS Compliant MEMS digital output motion sensor: ultra low-power high performance 3-axis “femto” accelerometer Applications ■ Motion activated functions ■ Display orientation ■ Shake control ■ Pedometer ■ Gaming and virtual reality input devices ■ Impact recognition and logging
Data sheet Physical Case/Package LGA Mount Surface Mount Number of Pins 16 Technical Axis X, Y, Z Bandwidth 500 Hz Interface I2C , SPI Max Operating Temperature 85 °C Max Supply Voltage 3.6 V Min Operating Temperature -40 °C Min Supply Voltage 2.16 V Output Type Digital , SPI , I2C Resolution 16 b Sensor Type 3 Axis Dimensions Depth 3 mm Length 3 mm Compliance Lead Free Lead Free Radiation Hardening No RoHS Compliant MEMS motion sensor: low-power high-g 3-axis digital accelerometer
Data sheet Physical Case/Package R Number of Pins 8 Technical Common Mode Rejection Ratio 110 dB Dual Supply Voltage 15 V Gain Bandwidth Product 75 kHz Input Bias Current 20 nA Input Offset Voltage (Vos) 500 µV Max Dual Supply Voltage 18 V Max Operating Temperature 125 °C Max Supply Voltage 36 V Min Dual Supply Voltage 1.5 V Min Operating Temperature -40 °C Min Supply Voltage 3 V Nominal Supply Current 300 µA Number of Amplifiers 2 Number of Channels 2 Number of Circuits 2 Number of Elements 2 Operating Supply Current 350 µA Operating Supply Voltage 28 V Output Current per Channel 25 mA Power Supply Rejection Ratio (PSRR) 110 dB Quiescent Current 150 µA Slew Rate 0.03 V/µs Unity Gain Bandwidth Product 75 kHz Voltage Gain 140 dB Compliance Lead Free Contains Lead Radiation Hardening No RoHS Compliant Rail-to-rail output swing combined with dc accuracy are the key features of the OP495 quad and OP295 dual CBCMOS operational amplifiers. By using a bipolar front end, lower noise and higher accuracy than those of CMOS designs have been achieved. Both input and output ranges include the negative supply, providing the user with zero-in/zero-out capability. For users of 3.3 V systems such as lithium batteries, the OP295/OP495 are specified for 3 V operation. Maximum offset voltage is specified at 300 µV for 5 V operation, and the open-loop gain is a minimum of 1000 V/mV. This yields performance that can be used to implement high accuracy systems, even in single-supply designs. The ability to swing rail-to-rail and supply 15 mA to the load makes the OP295/OP495 ideal drivers for power transistors and H bridges. This allows designs to achieve higher efficiencies and to transfer more power to the load than previously possible without the use of discrete components. For applications such as transformers that require driving inductive loads, increases in efficiency are also possible. Stability while driving capacitive loads is another benefit of this design over CMOS rail-to-rail amplifiers. This is useful for driving coax cable or large FET transistors. The OP295/OP495 are stable with loads in excess of 300 pF. The OP295 and OP495 are specified over the extended indus-trial (-40°C to +125°C) temperature range. The OP295 is available in 8-lead PDIP and 8-lead SOIC_N surface-mount packages. The OP495 is available in 14-lead PDIP and 16-lead SOIC_W surface-mount packages. Applications Battery-operated instrumentation Servo amplifiers Actuator drives Sensor conditioners Power supply control
Data sheet Physical Contact Plating Copper , Tin , Silver Mount Surface Mount Technical Logic Function Receiver Max Operating Temperature 125 °C Min Operating Temperature -40 °C Operating Supply Current 2.5 A Compliance Lead Free Lead Free RoHS Compliant 5-W (WPC) Single-Chip Wireless Power Receiver with I2C 42-DSBGA -40 to 125
Data sheet Physical Case/Package SOIC Mount Surface Mount Number of Pins 24 Technical Conversion Rate 15 kS/s Dual Supply Voltage 5 V Interface SPI , Serial Max Dual Supply Voltage 5.25 V Max Operating Temperature 85 °C Min Dual Supply Voltage 4.75 V Min Operating Temperature -40 °C Number of A/D Converters 1 Number of Analog Inputs 1 Number of Bits 20 Number of Channels 1 Number of Converters 1 Number of Elements 1 Polarity Bipolar , Unipolar Resolution 20 b Sampling Rate 15 kS/s Supply Type Dual , Analog , Digital Compliance Lead Free Lead Free Radiation Hardening No RoHS Compliant 20-BIT ANALOG-TO-DIGITAL CONVERTER The DDC101 is a precision, wide dynamic range, charge digitizing A/D converter with 20-bit resolution. Lowlevel current output devices, such as photosensors, can bedirectly connected to its input. The most stringent accuracy requirements of many unipolar output sensor applications occur at low signal levels. To meet this requirement, Burr-Brown developed the adaptive delta odulation architecture of the DDC101 to provide linearly improving noise and linearity errors as the input signal level decreases. The DDC101 combines the functions of current-to-voltage conversion, integration, input programmable gain amplification, A/D conversion, and digital filtering to produce precision, wide dynamic range results. The input signal can be a low level current connected directly into the unit or a voltage connected through a user selected resistor. Although the DDC101 is optimized for unipolar signals, it can also accurately digitize bipolar input signals. The patented delta modulation topology combines charge integration and digitization functions. Oversampling and digital filtering reduce system noise dramatically. Correlated Double Sampling (CDS) captures and eliminates steady state and conversion cycle dependent offset and switching errors that are not eliminated with conventional analog circuits. The DDC101 block diagram is shown below. During conversion, the input signal is collected on the Internal integration capacitance for a user determined integration period. A high precision, autozeroed comparator samples the analog input node. Tracking logic updates the internal high resolution D/A converter at a 2MHz rate to maintain the analog input at virtual ground. A user programmable digital filter oversamples the tracking logic’s output. The digital filter passes a low noise, high resolution digital output to the serial I/O register. The serial outputs of multiple DDC101 units can be easily connected together in series or parallel if desired to minimize interconnections.
Data sheet Physical Mount Surface Mount Number of Pins 16 Technical Max Operating Temperature 125 °C Min Input Voltage 2.2 V Min Operating Temperature 0 °C Number of Outputs 1 Output Current 1.5 A Quiescent Current 400 µA Compliance RoHS Compliant IC REGULATOR DDR TERM 16WQFN
Data sheet Physical Case/Package CDIP Contact Plating Tin , Lead Mount Through Hole Number of Pins 16 Technical High Level Output Current -5.2 mA Logic Function Buffer Low Level Output Current 26 mA Max Operating Temperature 125 °C Max Supply Voltage 20 V Min Operating Temperature -55 °C Min Supply Voltage -500 mV Number of Bits 6 Number of Channels 6 Number of Elements 6 Number of Inputs 6 Number of Outputs 6 Polarity Non-Inverting Propagation Delay 140 ns Quiescent Current 20 µA Turn-On Delay Time 140 ns Compliance Lead Free Contains Lead Radiation Hardening No RoHS Compliant CMOS Hex Non-Inverting Buffer/Converter 16-CDIP -55 to 125
