Part No .:
LIS2DHTRManufacturer:
STMicroeletronicsDescription:
memsRemark:
new originLast Updated:
2025/06/26
|
Physical
|
|
| Case/Package | LGA |
| Contact Plating | Nickel , Gold |
| Number of Pins | 14 |
|
Technical
|
|
| Axis | X, Y, Z |
| Bandwidth | 5.3 kHz |
| Interface | I2C , SPI |
| Max Operating Temperature | 85 °C |
| Max Supply Voltage | 3.6 V |
| Max Supply Voltage (DC) | 3.6 V |
| Min Operating Temperature | -40 °C |
| Min Supply Voltage | 1.71 V |
| Min Supply Voltage (DC) | 1.71 V |
| Operating Supply Current | 2 µA |
| Output Type | Digital |
| Sensor Type | 3 Axis |
|
Dimensions
|
|
| Height | 1 mm |
| Length | 2.15 mm |
| Width | 2.15 mm |
|
Compliance
|
|
| Lead Free | Lead Free |
| REACH SVHC | No SVHC |
| Radiation Hardening | No |
| RoHS | Compliant |
Applications
■ Motion activated functions
■ Display orientation
■ Shake control
■ Pedometer
■ Gaming and virtual reality input devices
■ Impact recognition and logging
