Part No .:
IIS328DQTRManufacturer:
STMicroeletronicsDescription:
memsRemark:
new originLast Updated:
2025/06/26
|
Physical
|
|
| Case/Package | QFN |
| Mount | Surface Mount |
| Number of Pins | 24 |
|
Technical
|
|
| Axis | X, Y, Z |
| Bandwidth | 500 Hz |
| Max Operating Temperature | 105 °C |
| Max Supply Voltage | 3.6 V |
| Min Operating Temperature | -40 °C |
| Min Supply Voltage | 2.16 V |
| Output Type | SPI , I2C |
|
Compliance
|
|
| Lead Free | Lead Free |
| REACH SVHC | No SVHC |
| RoHS | Compliant |
Data sheet Physical Mount Surface Mount Number of Pins 16 Technical Axis X, Y, Z Bandwidth 200 Hz Max Operating Temperature 85 °C Max Supply Voltage 3.6 V Min Operating Temperature -40 °C Min Supply Voltage 2.16 V Output Type SPI , I2C Compliance Lead Free Lead Free REACH SVHC No SVHC RoHS Compliant MEMS motion sensor: low-power high-g 3-axis digital accelerometer
MEMS motion sensor: low-power high-g 3-axis digital accelerometer The H3LIS100DL is a low-power highperformance 3-axis linear accelerometer belonging to the “nano” family, with digital I2C/SPI serial interface standard output. The device features ultra-low-power operational modes that allow advanced power saving and smart sleep-to-wakeup functions. The H3LIS100DL has a full scale of ±100 g and is capable of measuring accelerations with output data rates from 0.5 Hz to 400 Hz. The H3LIS100DL is available in a small thin plastic land grid array package (LGA) and is guaranteed to operate over an extended temperature range from -40 °C to +85 °C.
Data sheet Physical Case/Package QFN Contact Plating Tin Mount Surface Mount Number of Pins 2400% Technical Axis X, Y, Z Bandwidth 500 Hz Max Operating Temperature 105 °C Min Operating Temperature -40 °C Operating Supply Voltage 3.6 V Output Type SPI , I2C , Digital Compliance RoHS Compliant High-performance motion sensor for automotive applications: ultra-low-power digital output 3-axis accelerometer The AIS3624DQ is available in a small quad flat no-lead (QFN) package (4x4 mm footprint) and is guaranteed to operate over an extended temperature range from -40 °C to +105 °C. This product may be used in a variety of automotive non-safety applications such as: Motion-activated functions Telematic boxes Impact recognition and logging Vibration monitoring and compensation
Data sheet Physical Case/Package LGA Contact Plating Nickel , Gold Number of Pins 14 Technical Axis X, Y, Z Bandwidth 5.3 kHz Interface I2C , SPI Max Operating Temperature 85 °C Max Supply Voltage 3.6 V Max Supply Voltage (DC) 3.6 V Min Operating Temperature -40 °C Min Supply Voltage 1.71 V Min Supply Voltage (DC) 1.71 V Operating Supply Current 2 µA Output Type Digital Sensor Type 3 Axis Dimensions Height 1 mm Length 2.15 mm Width 2.15 mm Compliance Lead Free Lead Free REACH SVHC No SVHC Radiation Hardening No RoHS Compliant MEMS digital output motion sensor: ultra low-power high performance 3-axis “femto” accelerometer Applications ■ Motion activated functions ■ Display orientation ■ Shake control ■ Pedometer ■ Gaming and virtual reality input devices ■ Impact recognition and logging
Data sheet MEMS inertial sensor high performance 3-axis ±2/±6g ultracompact linear accelerometer Physical Case/Package LGA Contact Plating Nickel , Gold Mount Surface Mount Number of Pins 1600% Technical Axis X, Y, Z Bandwidth 2 kHz Max Operating Temperature 85 °C Max Supply Voltage 3.6 V Min Operating Temperature -40 °C Min Supply Voltage 2.4 V Nominal Supply Current 680 µA Output Type Analog Sensitivity 15000 mV/g Dimensions Height 1.33 mm Length 4.15 mm Width 4.15 mm Compliance Lead Free Lead Free Radiation Hardening No RoHS Compliant
Data sheet Physical Case/Package LGA Mount Surface Mount Number of Pins 16 Technical Axis X, Y, Z Bandwidth 500 Hz Interface I2C , SPI Max Operating Temperature 85 °C Max Supply Voltage 3.6 V Min Operating Temperature -40 °C Min Supply Voltage 2.16 V Output Type Digital , SPI , I2C Resolution 16 b Sensor Type 3 Axis Dimensions Depth 3 mm Length 3 mm Compliance Lead Free Lead Free Radiation Hardening No RoHS Compliant MEMS motion sensor: low-power high-g 3-axis digital accelerometer
Data sheet Physical Case/Package Module Contact Plating Tin Mount Screw Number of Pins 24 Technical -3db Bandwidth 330 Hz Interface SPI Max Operating Temperature 105 °C Max Supply Voltage 5.25 V Min Operating Temperature -40 °C Min Supply Voltage 4.75 V Nominal Supply Current 45 mA Operating Supply Current 45 mA Output Type SPI Sensor Type Accelerometer , Gyroscope , Magnetometer , 3 Axis Dimensions Height 23.504 mm Length 23.45 mm Width 22.964 mm Compliance Lead Free Contains Lead REACH SVHC No SVHC RoHS Compliant The ADIS16400/ADIS16405 iSensor® products are complete inertial systems that include a triaxal gyroscope, a triaxial accelerometer, and a triaxial magnetometer. The ADIS16400/ ADIS16405 combine industry-leading iMEMS® technology with signal conditioning that optimizes dynamic performance. The factory calibration characterizes each sensor for sensitivity, bias, alignment, and linear acceleration (gyroscope bias). As a result, each sensor has its own dynamic compensation for correction formulas that provide accurate sensor measurements over a temperature range of -40°C to +85°C. The magnetometers employ a self-correction function to provide accurate bias performance over temperature, as well. The ADIS16400/ADIS16405 provide a simple, cost-effective method for integrating accurate, multi-axis inertial sensing into industrial systems, especially when compared with the complexity and investment associated with discrete designs. All necessary motion testing and calibration are part of the production process at the factory, greatly reducing system integration time. Tight orthogonal alignment simplifies inertial frame alignment in navigation systems. An improved serial peripheral interface (SPI) and register structure provide faster data collection and configuration control. By using a compatible pinout and the same package as the ADIS1635x and ADIS1636x families, upgrading to the ADIS16400/ADIS16405 requires only firmware changes to accommodate additional sensors and register map updates. These compact modules are approximately 23 mm × 23 mm × 23 mm and provide a flexible connector interface that enables multiple mounting orientation options.
Data sheet Physical Case/Package Q Contact Plating Tin , Lead Number of Pins 8 Technical Common Mode Rejection Ratio 95 dB Gain Bandwidth Product 30 MHz Input Bias Current 3.3 µA Input Capacitance 1.5 pF Input Offset Voltage (Vos) 1 mV Input Voltage Noise Density 15 nV/sqrt Hz Max Dual Supply Voltage 18 V Max Operating Temperature 125 °C Max Power Dissipation 1.1 W Max Supply Voltage 36 V Min Dual Supply Voltage 4.5 V Min Operating Temperature -55 °C Min Supply Voltage 9 V Number of Amplifiers 1 Number of Channels 1 Number of Elements 1 Operating Supply Current 5.3 mA Power Dissipation 1.1 W Power Supply Rejection Ratio (PSRR) 86 dB Quiescent Current 4.8 mA Settling Time 120 ns Slew Rate 300 V/µs Unity Gain Bandwidth Product 35 MHz Voltage Gain 70.88 dB Compliance Lead Free Contains Lead Radiation Hardening No RoHS Compliant The AD847 represents a breakthrough in high speed amplifiers offing superior ac & dc perfomance and low power, all at low cost. The excellent dc performance is demonstrated by its ±5 V specifications which include an open-loop gain of 3500 V/V (500 Ohm load) and low input offset voltage of 0.5 mV. Common-mode rejection is a minimum of 78 dB. Output voltage swing is ±3 V into loads as low as 150 Ohm. Analog Devices also offers over 30 other high speed amplifiers from the low noise AD829 (1.7nV/(root)Hz) to the ultimate video amplifier, the AD811, which features 0.01% differential gain and 0.01° differential phase.
Data sheet Physical Case/Package PDIP Contact Plating Tin Mount Through Hole Number of Pins 8 Weight 0.032805 oz Technical Density 512 kb Interface Serial , 2-Wire Max Frequency 15 MHz Max Operating Temperature 85 °C Max Supply Voltage 5.5 V Memory Size 512 kb Memory Type EEPROM Min Operating Temperature -40 °C Min Supply Voltage 3 V Nominal Supply Current 10 mA Operating Supply Current 10 mA Compliance Lead Free Lead Free Radiation Hardening No RoHS Non-Compliant The Atmel® AT17LVxxxA FPGA configuration EEPROMs (Configurators) provide an easy-to-use, cost-effective configuration memory solution for FPGAs. The AT17LVxxxA are packaged in 8-lead PDIP and 20-lead PLCC options. The AT17LVxxxA configurator uses a simple serial-access procedure to configure one or more FPGA devices. The user can select the polarity of the reset function by programming four EEPROM bytes. These devices support a write protection mechanism within its programming mode.
Data sheet Physical Case/Package CDIP Contact Plating Tin , Lead Mount Through Hole Number of Pins 14 Technical Common Mode Rejection Ratio 60 dB Input Bias Current 1 nA Input Offset Voltage (Vos) 2 mV Max Dual Supply Voltage 15 V Max Operating Temperature 125 °C Max Power Dissipation 1.2 W Max Supply Voltage 30 V Min Dual Supply Voltage 2.5 V Min Operating Temperature -55 °C Min Supply Voltage 5 V Nominal Supply Current 2 mA Number of Channels 4 Number of Elements 4 Output Current 16 mA Power Dissipation 1.2 W Power Supply Rejection Ratio (PSRR) 60 dB Response Time 5 µs Voltage Gain 93.98 dB Compliance Lead Free Contains Lead Radiation Hardening No RoHS Compliant Low Power Low Offset Voltage Quad Comparator 14-CDIP -55 to 125 Application areas include limit comparators, simple analog to digital converters; pulse, squarewave and time delay generators; wide range VCO; MOS clock timers; multivibrators and high voltage digital logic gates. The LM139 series was designed to directly interface with TTL and CMOS. When operated from both plus and minus power supplies, they will directly interface with MOS logic— where the low power drain of the LM139/LM139A is a distinct advantage over standard comparators.
Data sheet Physical Mount Surface Mount Number of Pins 8 Technical Density 8 Mb Frequency 33 MHz Interface Serial , 2-Wire Max Frequency 33 MHz Max Operating Temperature 85 °C Max Supply Voltage 3.63 V Memory Size 8 Mb Min Operating Temperature -40 °C Min Supply Voltage 2.97 V Nominal Supply Current 20 mA Operating Supply Current 20 mA Operating Supply Voltage 3.3 V Compliance Lead Free Contains Lead RoHS Non-Compliant The AT17F Series of In-System Programmable Configuration PROMs (Configurators) provide an easy-to-use, cost-effective configuration memory for Field Programmable Gate Arrays. The AT17F Series device is packaged in the 8-lead LAP, 20-lead PLCC, 44-lead PLCC and 44-lead TQFP, see Table 1-1. The AT17F Series Configurator uses a simple serial-access procedure to configure one or more FPGA devices. The AT17F Series Configurators can be programmed with industry-standard programmers, Atmel’s ATDH2200E Programming Kit or Atmel’s ATDH2225 ISP Cable. FPGA Configuration Flash Memory
