Part No .:
H3LIS100DLTRManufacturer:
STMicroeletronicsDescription:
MEMSRemark:
new originLast Updated:
2026/01/28
|
Physical
|
|
| Mount | Surface Mount |
| Number of Pins | 16 |
|
Technical
|
|
| Axis | X, Y, Z |
| Bandwidth | 200 Hz |
| Max Operating Temperature | 85 °C |
| Max Supply Voltage | 3.6 V |
| Min Operating Temperature | -40 °C |
| Min Supply Voltage | 2.16 V |
| Output Type | SPI , I2C |
|
Compliance
|
|
| Lead Free | Lead Free |
| REACH SVHC | No SVHC |
| RoHS | Compliant |
MEMS motion sensor: low-power high-g 3-axis digital accelerometer The H3LIS100DL is a low-power highperformance 3-axis linear accelerometer belonging to the “nano” family, with digital I2C/SPI serial interface standard output. The device features ultra-low-power operational modes that allow advanced power saving and smart sleep-to-wakeup functions. The H3LIS100DL has a full scale of ±100 g and is capable of measuring accelerations with output data rates from 0.5 Hz to 400 Hz. The H3LIS100DL is available in a small thin plastic land grid array package (LGA) and is guaranteed to operate over an extended temperature range from -40 °C to +85 °C.
Data sheet Physical Case/Package QFN Mount Surface Mount Number of Pins 24 Technical Axis X, Y, Z Bandwidth 500 Hz Max Operating Temperature 105 °C Max Supply Voltage 3.6 V Min Operating Temperature -40 °C Min Supply Voltage 2.16 V Output Type SPI , I2C Compliance Lead Free Lead Free REACH SVHC No SVHC RoHS Compliant High-performance ultra-low-power 3-axis accelerometer with digital output for industrial applications
Data sheet Physical Case/Package QFN Contact Plating Tin Mount Surface Mount Number of Pins 2400% Technical Axis X, Y, Z Bandwidth 500 Hz Max Operating Temperature 105 °C Min Operating Temperature -40 °C Operating Supply Voltage 3.6 V Output Type SPI , I2C , Digital Compliance RoHS Compliant High-performance motion sensor for automotive applications: ultra-low-power digital output 3-axis accelerometer The AIS3624DQ is available in a small quad flat no-lead (QFN) package (4x4 mm footprint) and is guaranteed to operate over an extended temperature range from -40 °C to +105 °C. This product may be used in a variety of automotive non-safety applications such as: Motion-activated functions Telematic boxes Impact recognition and logging Vibration monitoring and compensation
Data sheet Physical Case/Package LGA Contact Plating Nickel , Gold Number of Pins 14 Technical Axis X, Y, Z Bandwidth 5.3 kHz Interface I2C , SPI Max Operating Temperature 85 °C Max Supply Voltage 3.6 V Max Supply Voltage (DC) 3.6 V Min Operating Temperature -40 °C Min Supply Voltage 1.71 V Min Supply Voltage (DC) 1.71 V Operating Supply Current 2 µA Output Type Digital Sensor Type 3 Axis Dimensions Height 1 mm Length 2.15 mm Width 2.15 mm Compliance Lead Free Lead Free REACH SVHC No SVHC Radiation Hardening No RoHS Compliant MEMS digital output motion sensor: ultra low-power high performance 3-axis “femto” accelerometer Applications ■ Motion activated functions ■ Display orientation ■ Shake control ■ Pedometer ■ Gaming and virtual reality input devices ■ Impact recognition and logging
Data sheet MEMS inertial sensor high performance 3-axis ±2/±6g ultracompact linear accelerometer Physical Case/Package LGA Contact Plating Nickel , Gold Mount Surface Mount Number of Pins 1600% Technical Axis X, Y, Z Bandwidth 2 kHz Max Operating Temperature 85 °C Max Supply Voltage 3.6 V Min Operating Temperature -40 °C Min Supply Voltage 2.4 V Nominal Supply Current 680 µA Output Type Analog Sensitivity 15000 mV/g Dimensions Height 1.33 mm Length 4.15 mm Width 4.15 mm Compliance Lead Free Lead Free Radiation Hardening No RoHS Compliant
Data sheet Physical Case/Package LGA Mount Surface Mount Number of Pins 16 Technical Axis X, Y, Z Bandwidth 500 Hz Interface I2C , SPI Max Operating Temperature 85 °C Max Supply Voltage 3.6 V Min Operating Temperature -40 °C Min Supply Voltage 2.16 V Output Type Digital , SPI , I2C Resolution 16 b Sensor Type 3 Axis Dimensions Depth 3 mm Length 3 mm Compliance Lead Free Lead Free Radiation Hardening No RoHS Compliant MEMS motion sensor: low-power high-g 3-axis digital accelerometer
Data sheet Physical Case/Package SOIC Number of Pins 16 Weight 0.016709 oz Technical Input Current 6 mA Max Operating Temperature 85 °C Min Operating Temperature -40 °C Operating Supply Current 6 mA Operating Supply Voltage 35 V Dimensions Height 2.35 mm Length 10.28 mm Compliance Lead Free Lead Free Radiation Hardening No RoHS Compliant Load Share Controller 16-SOIC -40 to 85
Data sheet Physical Case/Package Module Mount Screw Number of Pins 24 Technical -3db Bandwidth 330 Hz Max Operating Temperature 85 °C Max Supply Voltage 3.6 V Min Operating Temperature -40 °C Min Supply Voltage 3 V Nominal Supply Current 254 mA Operating Supply Current 254 mA Output Type SPI Sensor Type Accelerometer , Gyroscope , Magnetometer , 3 Axis Compliance Lead Free Contains Lead REACH SVHC No SVHC RoHS Compliant The ADIS16488A iSensor® device is a complete inertial system that includes a triaxis gyroscope, a triaxis accelerometer, triaxis magnetometer, and pressure sensor. Each inertial sensor in the ADIS16488A combines industry-leading iMEMS® technology with signal conditioning that optimizes dynamic performance. The factory calibration characterizes each sensor for sensitivity, bias, alignment, and linear acceleration (gyroscope bias). As a result, each sensor has its own dynamic compensation formulas that provide accurate sensor measurements. The ADIS16488A provides a simple, cost-effective method for integrating accurate, multiaxis inertial sensing into industrial systems, especially when compared with the complexity and investment associated with discrete designs. All necessary motion testing and calibration are part of the production process at the factory, greatly reducing system integration time. Tight orthogonal alignment simplifies inertial frame alignment in navigation systems. The SPI and register structure provide a simple interface for data collection and configuration control. The ADIS16488A uses the same footprint and connector system as the ADIS16375, ADIS16480, and ADIS16485, which greatly simplifies the upgrade process. The ADIS16488A is packaged in a module that is approximately 47 mm × 44 mm × 14 mm and includes a standard connector interface. Applications Platform stabilization and control Navigation Personnel tracking Instrumenta
Physical Case/Package SSOP Mount Surface Mount Number of Pins 16 Technical Logic Function Multiplexer Max Dual Supply Voltage 20 V Max Operating Temperature 85 °C Max Supply Voltage 30 V Min Dual Supply Voltage 4.5 V Min Operating Temperature -40 °C Min Supply Voltage 4.5 V On-State Resistance 400 Ω Operating Supply Current 1 µA Supply Type Single , Dual Compliance Radiation Hardening No RoHS Non-Compliant Maxim Integrated MAX339EEE+T Analog Multiplexer Dual 4:1 16-Pin QSOP T/R
Data sheet Physical Case/Package SOIC W Number of Pins 20 Technical Dual Supply Voltage 15 V Interface Parallel Max Dual Supply Voltage 20 V Max Operating Temperature 85 °C Max Power Dissipation 3.77 mW Max Supply Current 250 µA Max Supply Voltage 30 V Min Dual Supply Voltage 3 V Min Operating Temperature -40 °C Min Supply Voltage 3 V Number of Bits 4 Number of Channels 4 Number of Circuits 4 Number of Inputs 4 Number of Outputs 8 On-State Resistance 45 Ω Operating Supply Current 50 nA Operating Supply Voltage 12 V Supply Type Single , Dual Test Frequency 1 MHz Throw Configuration SPDT Turn-Off Delay Time 145 ns Turn-On Delay Time 175 ns Compliance Lead Free Contains Lead Radiation Hardening No RoHS Compliant The ADG333A is a monolithic complementary metal-oxide semiconductor (CMOS) device comprising four independently selectable single-pole, double-throw (SPDT) switches. It is designed on a linear compatible CMOS (LC2MOS) process, which provides low power dissipation yet achieves a high switching speed and a low on resistance. The on-resistance profile is very flat over the full analog input range, ensuring good linearity and low distortion when switching audio signals. High switching speed also makes the device suitable for video signal switching. CMOS construction ensures ultralow power dissipation, making the device ideally suited for portable, battery-powered instruments. When they are on, each switch conducts equally well in both directions and has an input signal range that extends to the power supplies. In the off condition, signal levels up to the supplies are blocked. All switches exhibit break-before-make switching action for use in multiplexer applications. Low charge inject is inherent in the design. Product Highlights Extended signal range. The ADG333A is fabricated on an enhanced LC2MOS process, giving an increased signal range which extends to the supply rails. Low power dissipation. Low RON. Single-supply operation. For applications in which the analog signal is unipolar, the ADG333A can be operated from a single rail power supply. The device is fully specified with a single 12 V supply. Applications Audio and video switching Battery-powered systems Test equipment Communication systems
Data sheet Physical Case/Package LCC Contact Plating Nickel , Gold Number of Pins 8 Technical -3db Bandwidth 2.5 kHz Axis X, Y Bandwidth 0.5 Hz Frequency 5.5 kHz Max Operating Temperature 125 °C Max Supply Voltage 6 V Min Operating Temperature -40 °C Min Supply Voltage 3 V Nominal Supply Current 700 µA Operating Supply Current 700 µA Operating Supply Voltage 3.3 V Output Type Analog Sensitivity 1000 mV/g Dimensions Depth 5 mm Height 1.98 mm Length 5 mm Width 5 mm Compliance Lead Free Contains Lead REACH SVHC No SVHC Radiation Hardening No RoHS Compliant The ADXL103/ADXL203 are high precision, low power, complete single- and dual-axis accelerometers with signal conditioned voltage outputs, all on a single, monolithic IC. The ADXL103/ADXL203 measure acceleration with a full-scale range of ±1.7 g, ±5 g, ±18 g. The ADXL103/ADXL203 can measure both dynamic acceleration (for example, vibration) and static acceleration (for example, gravity). A typical noise floor as low as 110 µg/√Hz, allows signals below 1 mg (0.06° of inclination) to be resolved in tilt sensing applications using narrow bandwidths (<60 Hz). The user selects the bandwidth of the accelerometer using Capacitor CX and Capacitor CY at the XOUT and YOUT pins. Bandwidths of 0.5 Hz to 2.5 kHz may be selected to suit the application. The ADXL103 and ADXL203 are available in 5 mm × 5 mm × 2 mm, 8-pad hermetic LCC packages. Applications Vehicle dynamic control (VDC)/electronic stability program (ESP) systems Electronic chassis control Electronic braking Platform stabilization/leveling Navigation Alarms and motion detectors High accuracy, 2-axis tilt sensing
