Part No .:
AIS3624DQTRManufacturer:
STMicroeletronicsDescription:
MEMSRemark:
new originLast Updated:
2026/08/13
|
Physical
|
|
| Case/Package | QFN |
| Contact Plating | Tin |
| Mount | Surface Mount |
| Number of Pins | 2400% |
|
Technical
|
|
| Axis | X, Y, Z |
| Bandwidth | 500 Hz |
| Max Operating Temperature | 105 °C |
| Min Operating Temperature | -40 °C |
| Operating Supply Voltage | 3.6 V |
| Output Type | SPI , I2C , Digital |
|
Compliance
|
|
| RoHS | Compliant |
The AIS3624DQ is available in a small quad flat no-lead (QFN) package (4x4 mm footprint) and is guaranteed to operate over an extended temperature range from -40 °C to +105 °C.
This product may be used in a variety of automotive non-safety applications such as:
Motion-activated functions
Telematic boxes
Impact recognition and logging
Vibration monitoring and compensation
Data sheet Physical Mount Surface Mount Number of Pins 16 Technical Axis X, Y, Z Bandwidth 200 Hz Max Operating Temperature 85 °C Max Supply Voltage 3.6 V Min Operating Temperature -40 °C Min Supply Voltage 2.16 V Output Type SPI , I2C Compliance Lead Free Lead Free REACH SVHC No SVHC RoHS Compliant MEMS motion sensor: low-power high-g 3-axis digital accelerometer
MEMS motion sensor: low-power high-g 3-axis digital accelerometer The H3LIS100DL is a low-power highperformance 3-axis linear accelerometer belonging to the “nano” family, with digital I2C/SPI serial interface standard output. The device features ultra-low-power operational modes that allow advanced power saving and smart sleep-to-wakeup functions. The H3LIS100DL has a full scale of ±100 g and is capable of measuring accelerations with output data rates from 0.5 Hz to 400 Hz. The H3LIS100DL is available in a small thin plastic land grid array package (LGA) and is guaranteed to operate over an extended temperature range from -40 °C to +85 °C.
Data sheet Physical Case/Package QFN Mount Surface Mount Number of Pins 24 Technical Axis X, Y, Z Bandwidth 500 Hz Max Operating Temperature 105 °C Max Supply Voltage 3.6 V Min Operating Temperature -40 °C Min Supply Voltage 2.16 V Output Type SPI , I2C Compliance Lead Free Lead Free REACH SVHC No SVHC RoHS Compliant High-performance ultra-low-power 3-axis accelerometer with digital output for industrial applications
Data sheet Physical Case/Package LGA Contact Plating Nickel , Gold Number of Pins 14 Technical Axis X, Y, Z Bandwidth 5.3 kHz Interface I2C , SPI Max Operating Temperature 85 °C Max Supply Voltage 3.6 V Max Supply Voltage (DC) 3.6 V Min Operating Temperature -40 °C Min Supply Voltage 1.71 V Min Supply Voltage (DC) 1.71 V Operating Supply Current 2 µA Output Type Digital Sensor Type 3 Axis Dimensions Height 1 mm Length 2.15 mm Width 2.15 mm Compliance Lead Free Lead Free REACH SVHC No SVHC Radiation Hardening No RoHS Compliant MEMS digital output motion sensor: ultra low-power high performance 3-axis “femto” accelerometer Applications ■ Motion activated functions ■ Display orientation ■ Shake control ■ Pedometer ■ Gaming and virtual reality input devices ■ Impact recognition and logging
Data sheet MEMS inertial sensor high performance 3-axis ±2/±6g ultracompact linear accelerometer Physical Case/Package LGA Contact Plating Nickel , Gold Mount Surface Mount Number of Pins 1600% Technical Axis X, Y, Z Bandwidth 2 kHz Max Operating Temperature 85 °C Max Supply Voltage 3.6 V Min Operating Temperature -40 °C Min Supply Voltage 2.4 V Nominal Supply Current 680 µA Output Type Analog Sensitivity 15000 mV/g Dimensions Height 1.33 mm Length 4.15 mm Width 4.15 mm Compliance Lead Free Lead Free Radiation Hardening No RoHS Compliant
Data sheet Physical Case/Package LGA Mount Surface Mount Number of Pins 16 Technical Axis X, Y, Z Bandwidth 500 Hz Interface I2C , SPI Max Operating Temperature 85 °C Max Supply Voltage 3.6 V Min Operating Temperature -40 °C Min Supply Voltage 2.16 V Output Type Digital , SPI , I2C Resolution 16 b Sensor Type 3 Axis Dimensions Depth 3 mm Length 3 mm Compliance Lead Free Lead Free Radiation Hardening No RoHS Compliant MEMS motion sensor: low-power high-g 3-axis digital accelerometer
Data sheet Physical Case/Package SOIC Mount Surface Mount Number of Pins 24 Technical Conversion Rate 15 kS/s Dual Supply Voltage 5 V Interface SPI , Serial Max Dual Supply Voltage 5.25 V Max Operating Temperature 85 °C Min Dual Supply Voltage 4.75 V Min Operating Temperature -40 °C Number of A/D Converters 1 Number of Analog Inputs 1 Number of Bits 20 Number of Channels 1 Number of Converters 1 Number of Elements 1 Polarity Bipolar , Unipolar Resolution 20 b Sampling Rate 15 kS/s Supply Type Dual , Analog , Digital Compliance Lead Free Lead Free Radiation Hardening No RoHS Compliant 20-BIT ANALOG-TO-DIGITAL CONVERTER The DDC101 is a precision, wide dynamic range, charge digitizing A/D converter with 20-bit resolution. Lowlevel current output devices, such as photosensors, can bedirectly connected to its input. The most stringent accuracy requirements of many unipolar output sensor applications occur at low signal levels. To meet this requirement, Burr-Brown developed the adaptive delta odulation architecture of the DDC101 to provide linearly improving noise and linearity errors as the input signal level decreases. The DDC101 combines the functions of current-to-voltage conversion, integration, input programmable gain amplification, A/D conversion, and digital filtering to produce precision, wide dynamic range results. The input signal can be a low level current connected directly into the unit or a voltage connected through a user selected resistor. Although the DDC101 is optimized for unipolar signals, it can also accurately digitize bipolar input signals. The patented delta modulation topology combines charge integration and digitization functions. Oversampling and digital filtering reduce system noise dramatically. Correlated Double Sampling (CDS) captures and eliminates steady state and conversion cycle dependent offset and switching errors that are not eliminated with conventional analog circuits. The DDC101 block diagram is shown below. During conversion, the input signal is collected on the Internal integration capacitance for a user determined integration period. A high precision, autozeroed comparator samples the analog input node. Tracking logic updates the internal high resolution D/A converter at a 2MHz rate to maintain the analog input at virtual ground. A user programmable digital filter oversamples the tracking logic’s output. The digital filter passes a low noise, high resolution digital output to the serial I/O register. The serial outputs of multiple DDC101 units can be easily connected together in series or parallel if desired to minimize interconnections.
Data sheet Physical Case/Package TSSOP Mount Surface Mount Technical Max Operating Temperature 125 °C Min Operating Temperature -40 °C Operating Supply Current 3.6 mA Compliance RoHS Compliant IC MODULE PANEL TFT DISP 16TSSOP
Data sheet Physical Mount PCB Technical Evaluation Kit Yes Interface SPI , Serial Operating Supply Voltage 3.3 V Sensor Type Accelerometer , Gyroscope , 3 Axis Compliance Lead Free Contains Lead REACH SVHC No SVHC RoHS Compliant The ADIS16445 iSensor® device is a complete inertial system that includes a triaxial gyroscope and a triaxial accelerometer. Each sensor in the ADIS16445 combines industry-leading iMEMS® technology with signal conditioning that optimizes dynamic performance. The factory calibration characterizes each sensor for sensitivity, bias, alignment, and linear accel-eration (gyroscope bias). As a result, each sensor has its own dynamic compensation formulas that provide accurate sensor measurements. The ADIS16445 provides a simple, cost-effective method for integrating accurate, multiaxis inertial sensing into industrial systems, especially when compared with the complexity and investment associated with discrete designs. All necessary motion testing and calibration are part of the production process at the factory, greatly reducing system integration time. Tight orthogonal alignment simplifies inertial frame alignment in navigation systems. The SPI and register structures provide a simple interface for data collection and configuration control. The ADIS16445 has a compatible pinout for systems that currently use other Analog Devices, Inc., IMU products, such as the ADIS16334 or the ADIS16485. Applications Platform stabilization and control Navigation Robotics
Data sheet Physical Number of Pins 14 Technical Input Current 500 µA Max Operating Temperature 125 °C Min Operating Temperature -40 °C Operating Supply Current 500 µA Operating Supply Voltage 5.5 V Output Current 59 mA Compliance Lead Free Lead Free Radiation Hardening No RoHS Compliant AVS System Controller 14-WSON -40 to 125
Data sheet Physical Case/Package Module Number of Pins 14 Technical Max Operating Temperature 85 °C Min Operating Temperature -25 °C Output Type SPI Sensor Type Accelerometer , Gyroscope , 6 Axis , Temperature Compliance Lead Free Contains Lead The ADIS16460 iSensor® device is a complete inertial system that includes a triaxial gyroscope and a triaxial accelerometer. Each sensor in the ADIS16460 combines industry leading iMEMS® technology with signal conditioning that optimizes dynamic performance. The factory calibration characterizes each sensor for sensitivity, bias, and alignment. As a result, each sensor has its own dynamic compensation formulas that provide accurate sensor measurements. The ADIS16460 provides a simple, cost effective method for integrating accurate, multiaxis inertial sensing into industrial systems, especially when compared with the complexity and investment associated with discrete designs. All necessary motion testing and calibration are part of the production process at the factory, greatly reducing system integration time. Tight orthogonal alignment simplifies inertial frame alignment in navigation systems. The SPI and register structures provide a simple interface for data collection and configuration control. The ADIS16460 is in an aluminum module package that is approximately 22.4 mm × 22.4 mm × 9 mm and has a 14-pin connector interface. Applications Smart agriculture/construction machinery Unmanned aerial vehicles (UAVs)/drones, and navigation and payload stabilization Robotics Factory/industrial automation personnel/asset tracking
