Part No .:
CD4053BF3AManufacturer:
Texas InstrumentsDescription:
ICRemark:
new originLast Updated:
2025/12/04
|
Physical
|
|
| Case/Package | CDIP |
| Contact Plating | Tin , Lead |
| Mount | Through Hole |
| Number of Pins | 16 |
|
Technical
|
|
| Max Dual Supply Voltage | 9 V |
| Max Operating Temperature | 125 °C |
| Max Supply Voltage | 20 V |
| Min Dual Supply Voltage | 2.5 V |
| Min Operating Temperature | -55 °C |
| Min Supply Voltage | 3 V |
| Number of Channels | 3 |
| Number of Inputs | 6 |
| Number of Outputs | 3 |
|
Compliance
|
|
| Lead Free | Contains Lead |
| Radiation Hardening | No |
| RoHS | Compliant |
CMOS Triple 2-Channel Analog Multiplexer/Demultiplexer with Logic-Level Conversion 16-CDIP -55 to 125
