Part No .:
ADIS16485 BMLZManufacturer:
Analog devicesDescription:
MEMSRemark:
new originLast Updated:
2024/04/26
Physical
|
|
Mount | Screw |
Number of Pins | 24 |
Technical
|
|
-3db Bandwidth | 330 Hz |
Max Operating Temperature | 85 °C |
Min Operating Temperature | -40 °C |
Operating Supply Current | 197 mA |
Operating Supply Voltage | 3.6 V |
Output Type | SPI |
Sensor Type | Accelerometer , Gyroscope , Magnetometer , 3 Axis |
Compliance
|
|
Lead Free | Contains Lead |
RoHS | Compliant |
The ADIS16485 iSensor® device is a complete inertial system that includes a triaxial gyroscope and a triaxial accelerometer. Each inertial sensor in the ADIS16485 combines industry-leading iMEMS® technology with signal conditioning that optimizes dynamic performance. The factory calibration characterizes each sensor for sensitivity, bias, alignment, and linear acceleration (gyroscope bias). As a result, each sensor has its own dynamic compensation formulas that provide accurate sensor measurements. The ADIS16485 provides a simple, cost-effective method for integrating accurate, multiaxis inertial sensing into industrial systems, especially when compared with the complexity and investment associated with discrete designs. All necessary motion testing and calibration are part of the production process at the factory, greatly reducing system integration time. Tight orthogonal alignment simplifies inertial frame alignment in navigation systems. The SPI and register structure provide a simple interface for data collection and configuration control. The ADIS16485 uses the same footprint and connector system as the ADIS16375 and the ADIS16488A, which greatly simplifies the upgrade process. It comes in a module that is approximately 47 mm × 44 mm × 14 mm and has a standard connector interface. Applications Platform stabilization and control Navigation Personnel tracking Instruments Robotics
