Part No .:
ADG211AKPManufacturer:
Analog DevicesDescription:
ICRemark:
new originLast Updated:
2024/09/16
|
Physical
|
|
| Case/Package | PLCC |
| Contact Plating | Tin |
| Number of Pins | 20 |
|
Technical
|
|
| Dual Supply Voltage | 15 V |
| High Level Output Current | 30 mA |
| Interface | Parallel |
| Max Dual Supply Voltage | 22 V |
| Max Operating Temperature | 85 °C |
| Max Power Dissipation | 470 mW |
| Max Supply Current | 1 mA |
| Max Supply Voltage | 25 V |
| Min Operating Temperature | -40 °C |
| Number of Bits | 4 |
| Number of Channels | 4 |
| Number of Circuits | 4 |
| Number of Inputs | 4 |
| Number of Outputs | 4 |
| On-State Resistance | 115 Ω |
| Operating Supply Voltage | 5 V |
| Polarity | Non-Inverting |
| Supply Type | Dual |
| Throw Configuration | SPST |
| Turn-Off Delay Time | 450 ns |
| Turn-On Delay Time | 600 ns |
|
Dimensions
|
|
| Height | 4.53 mm |
| Length | 8.89 mm |
| Width | 8.89 mm |
|
Compliance
|
|
| Lead Free | Contains Lead |
| RoHS | Compliant |
The ADG211A is a monolithic CMOS device comprising four independently selectable switches. They are designed on an enhanced LC2MOS process which gives an increased signal handling capability of ±15 V. These switches also feature high switching speeds and low RON. The ADG211A switches are turned on with a logic low on the appropriate control input. Each switch conducts equally well in both directions when ON and each has an input signal range that extends to the supplies. All switches exhibit break-before-make switching action for use in multiplexer applications. Inherent in the design is low charge injection for minimum transients when switching the digital inputs.
