Home /Texas Instruments /

TS5A3159DCKRG4

TS5A3159DCKRG4

  • Part No .:

    TS5A3159DCKRG4
  • Manufacturer:

    Texas Instruments
  • Description:

    IC
  • Remark:

    new origin
  • Last Updated:

    2019/12/14
  • Product Details

Data Sheet


Physical
Case/Package SOT-70-6
Mount Surface Mount
Weight 8.8E-05 oz
Technical
Bandwidth 100 MHz
Max Operating Temperature 85 °C
Max Supply Current 100 nA
Max Supply Voltage 5.5 V
Min Operating Temperature -40 °C
Min Supply Voltage 1.65 V
Number of Channels 1
On-State Resistance 1.1 Ω
Operating Supply Current 100 nA
Supply Type Single
Throw Configuration SPDT
Turn-Off Delay Time 15 ns
Turn-On Delay Time 20 ns
Compliance
Lead Free Lead Free
Radiation Hardening No
RoHS Compliant

The TS5A3159 device is a single-pole double-throw
(SPDT) analog switch that is designed to operate from 1.65 V to 5.5 V. The device offers a low ON-state resistance and an excellent N-state resistance matching, with the break-before-make feature to prevent signal istortion during the transferring of a signal from one channel to another.
The device has excellent total harmonic distortion (THD) performance and consumes very low power. These features make this device suitable for portable audio aplications.
